Core Features
- Pump-suction sampling function for polluted gas can be added according to customer actual demands.
- Terminal data is transmitted to cloud platform in real time via wireless network to facilitate whole-process pollution source control.
- Adopt dynamic heating (DHS) humidity compensation and cross interference compensation for gaseous pollutants to guarantee stable data accuracy.
- Built-in breakpoint resume transmission function, the effective data transmission rate reaches more than 99%.
- Support 4G full-network wireless communication, realize synchronous data upload of multiple platforms.
- Reserve linkage interface to connect with on-site pollution control equipment for automatic governance linkage.
- Support expansion of external accessories, including outdoor LED display screen, warning alarm light and other peripheral devices.
Detailed Technical Parameters
| Category | Item | Detection Method | Measuring Range | Resolution | Accuracy / Indication Error | Lower Detection Limit |
|---|---|---|---|---|---|---|
| Gaseous Pollutants | SO₂ Sulfur Dioxide | Electrochemistry | 0 ~ 500 ppb | 0.1 ppb | ±10% FS | 5 ppb |
| NO₂ Nitrogen Dioxide | Electrochemistry | 0 ~ 500 ppb | 0.1 ppb | ±10% FS | 5 ppb | |
| O₃ Ozone | Electrochemistry | 0 ~ 500 ppb | 0.1 ppb | ±10% FS | 5 ppb | |
| CO Carbon Monoxide | Electrochemistry | 0 ~ 20 ppm | 0.1 ppm | ±10% FS | 0.2 ppm | |
| TVOC Total Volatile Organic Compounds | PID Photoionization Detection PID | 0 ~ 10 ppm | 0.1 ppm | ±5% FS | 1 ppm | |
| Particulate Matter | PM2.5 | Laser Scattering | 0~1000 / 0~10000 / 0~30000 μg/m³ | 0.1 μg/m³ | ±10% | 2 μg/m³ |
| PM10 | Laser Scattering | 0~1000 / 0~10000 / 0~30000 μg/m³ | 0.1 μg/m³ | ±10% | 2 μg/m³ | |
| TSP Total Suspended Particulates | Laser Scattering | 0~1000 / 0~10000 / 0~30000 μg/m³ | 0.1 μg/m³ | ±10% | 2 μg/m³ | |
| Meteorological Parameters | Temperature | / | -40 ~ 123.8 ℃ | 0.01 ℃ | ±0.4 ℃ | / |
| Humidity | / | 0 ~ 100 %RH | 0.01 %RH | ±3 %RH | / | |
| Atmospheric Pressure | / | 70 ~ 120 kPa | 1 Pa | ±250 Pa | / | |
| Wind Speed | / | 0 ~ 60 m/s | 0.1 m/s | ±1 m/s | / | |
| Wind Direction | / | 0 ~ 359 ° | 1 ° | ±1 ° | / |
Application Scenarios
- Urban comprehensive ambient air quality long-term monitoring
- Industrial park, chemical plant, power plant, landfill, incineration plant, sewage treatment plant pollution source monitoring
- Road, highway and tunnel traffic pollution real-time supervision
- Construction site dust and exhaust gas continuous monitoring
- Residential communities, primary schools, hospitals environmental air monitoring
- Forest, park, scenic spot ecological atmospheric environment monitoring
- Short-term atmospheric environmental impact assessment for engineering projects
Company Profile
Henan Oceanus Company, located in Henan, a land with a long history and profound cultural heritage, has been dedicated to the research, development, production, and sales of Safety and Environmental products since its establishment. With exquisite technology and outstanding quality, we have won widespread recognition in the global marketing.
01. Business areas
As a leader in the field of gas detectors and dust monitor system, Henan OCEANUS Import and Export Co., Ltd. continues to expand its business scope and provide customers around the world with customizable gas detectors and AQMS of various types and specifications.
02. Values and ideas
Our company upholds the core values of integrity and quality service, focusing more on friendship with our customers. We always adhere to integrity management, customer-centered, and provide a full range of pre-sales, sales, and after-sales services to ensure that customers can be worry-free when using our products.
03. Global Service Network
We have a comprehensive global service network, offering timely, professional pre-sales consultation, after-sales service, and technical support for overseas users. Regardless of where users are located, they can enjoy our attentive and thoughtful service.
04. Customer Service
With excellent products and services, Henan OCEANUS Import and Export Co., Ltd.’s gas detectors and environment monitoring devices have been exported to more than 100 countries around the world and have won widespread praise.
How To Cooperate With Us?
Henan OCEANUS Import and Export Company, located in Henan, a land with a long history and profound cultural heritage, has been dedicated to the research, development, production, and sales of ambient air quality monitoring systems since its establishment. With exquisite technology and outstanding quality, we have won widespread recognition in the global market.
If you need more details of the Air quality monitor station, welcome to contact us:
No. 2206, Wenhua Chanye Building Block B, No. 77, Shangding Road, Zhengzhou Area, Henan Pilot Free Trade Zone
Email: info@china-oceanus.com
Telephone: +86 0371 60998169
Mobile/Whatsapp: +86 15981942832
Mobile/Whatsapp: +86 13673683950
