Description:
OC-1000 handheld 4-in-1 gas detector can simultaneously detect Carbon Dioxide (CO₂), Carbon Monoxide (CO), Hydrogen Sulfide (H₂S), Volatile Organic Compounds (VOC).
Equipped with built-in pump suction sampling system. CO2, CO and H2S adopt high stability electrochemical sensors; VOC is matched with PID sensor to detect carbon oxide toxic gas, sulfide pollutants and organic volatiles in air.
Support real-time digital concentration display, two-stage adjustable audible & visual alarm, large capacity automatic data storage, optional thermal printer for on-site report output.
With ATEX and CE certifications, widely used in auto repair shops, sewage plants, chemical workshops, environmental law enforcement and closed space safety monitoring.
Features:
Semiconductor technology of ultra low power 32 bit microprocessor, 24 bit ADC acquisition chip, so with the high accuracy.
3.5 inch IPS industrial grade color screen.
Support Chinese or English operation menu.
Gas concentration unit available for PPM, %VOL, mg/m3.
For 1~5 gas detecting, gas type all be customized, supporting the PM2.5 particle counter sensor, and humidity sensor, etc.
Internal sampling pump for suction, the suction strength is adjustable in different level.
Explosion proof grade is Exia ⅡCT4.
Function:
Inspect the gas concentration and alarm when it reaches preset alarm level.
With auto-test and data recover function.
One-key operation to restore to factory default setting.
Temperature and pressure compensation.
Adjustable two-stage audible-visual alarm threshold value.
Powered by rechargeable lithium battery with big capacity.
Working under the micro negative pressure is available.
Overload protection, over charge protection, anti static interference, anti magnetic interference, etc.
Technical Specification:
| Gas type | Carbon Dioxide (CO₂), Carbon Monoxide (CO), Hydrogen Sulfide (H₂S), Volatile Organic Compounds (VOC). | ||
| Work principle | Electrochemical sensor for CO and H2S;
NDIR sensor for CO2; PID sensor for VOC gas. |
||
| Sampling mode | Pump-suction sampling | ||
| Measure range | CO2: 0~5000ppm
CO: 0~1000ppm H2S: 0~100ppm VOC: 0~10ppm customizable |
||
| Resolution | CO2: 1ppm
CO: 1ppm H2S: 0.01ppm VOC: 0.01ppm customizable |
||
| Precision | CO2: ±2%F.S
O2: ±3%F.S H2S: ±3%F.S VOC: ±3%F.S |
||
| Temp & Humidity testing range | Temperature: -40~120℃;
Humidity: 0~100% RH |
||
| Data storage function | With the capacity of the 100000 group of measuring data, by the software could be transmitted to the computer. | ||
| Printer | Optional mini-printer. | ||
| Response time | ≤20s(T90) | Recovery time | ≤20s |
| Repeatability | ≤±1% | Linearity | ≤±1% |
| Zero drift | ≤±1%(F.S/year) | Concentration unit | ppm, %vol, %lel, mg/m3 |
| Display | LCD display the Date, time, Temp& humidity, Gas concentration data, unit, status for the pump, alarm and battery. | ||
| Operation language | Chinese/English | Alarm mode | Audible, visual, vibration |
| Working temperature | -40~120℃ | Working humidity | 0-95%RH(non-condensing) |
| Working pressure | -30Kpa ~ 100Kpa | Explosion-proof grade | Ex ia IIC T4 Ga |
| Protection grade | IP65 | Shell material | ABS+PC |
| Dimensions | 220*88*55mm | Weight | 0.5KG |
| Standard accessory | Particle filter, box, instruction, USB charger , data line, calibration cap. | ||
Remark: If you need gas or measuring range not listed on the above, pls send us your details requirments for further discussion.
Applications:
- Automobile Repair Workshops
Detect CO2, CO from engine exhaust, VOC from paint and H2S from pipeline leakage.
- Sewage Treatment Plants
Monitor H2S odor pollution and flammable toxic gas accumulation in sewage pools.
- Chemical & Coating Factories
Detect VOC volatilized by paint raw materials and harmful gas accumulation in production area.
- Roadside Environmental Supervision
Portable design for random inspection of vehicle exhaust and ambient air pollutants.
- Environmental Law Enforcement Inspection
Mobile field monitoring to trace multi-type toxic air pollution sources.
- Underground Closed Space
Prevent poisoning risks caused by accumulated CO, H2S and organic volatile gas.
