Description:
OC-850 portable multi gas detector is a highly customizable industrial gas safety monitor, configured for simultaneous detection of CH4(Methane), CO(Carbon Monoxide), SO2(Sulfur Dioxide).
It supports dual sampling modes: diffusion sampling and optional pump suction sampling (1L/min). Equipped with high-precision industrial sensors, the unit delivers fast response and stable measurement data.
Built with Ex ib IIB T3 explosion-proof standard and IP65 protection grade, the detector adopts LCD real-time display, sound-light-vibration triple alarm, built-in data storage and long endurance battery. Perfect for mining, thermal power plant, metallurgy, chemical industry, flue gas inspection and confined space operation.
Features:
- Simultaneous real-time detection for CH4, CO and SO2 gas; supports customized combination of 1 to 5 kinds of gases
- Two optional sampling modes: diffusion sampling and pump suction sampling with flow rate of 1L/min
- Adopts imported high-precision industrial gas sensors, response time ≤10 seconds
- Equipped with sound, light and vibration triple alarm system to prevent missing alarms in noisy industrial environments
- Clear LCD display to show gas concentration value, gas type name and real-time alarm status
- Built-in storage chip, capable of recording and storing up to 9999 sets of alarm data for data traceability
- Complies with Ex ib IIB T3 explosion-proof standard and IP65 dustproof & waterproof protection grade
- Ultra-long working endurance: 100 hours continuous operation when the suction pump is closed
- Supports English & Chinese switchable system language; multiple optional gas units: PPM, %VOL, %LEL, mg/m³
- Wide working temperature range from -40℃ to 70℃, stable performance under severe industrial working conditions
- Built-in stainless steel filter screen to protect internal sensors and guarantee stable and smooth gas intake
Technical Specification:
| Gas Detected | CH4(Methane), CO(Carbon Monoxide), SO2(Sulfur Dioxide) | ||
| Detection principle | Catalytic combustion sensor: CH4, Electrochemical sensor: CO, SO2 | ||
| Sampling Method | Diffusion type or Pump suction(1L/min) | ||
| Measure Range | CH4: 0~100%vol, CO: 0~1000ppm, SO2: 0~100ppm; Support customized | ||
| Resolution | CH4: 0.01%vol, CO: 0.1 ppm, SO2: 0.01 ppm | ||
| Precision | ≤± 3% F.S. | ||
| Data store | 9999 groups alarm information | ||
| Response Time | ≤10S | Recovery Time | ≤10S |
| Repeatability | ≤±1% | Linearity error | ≤±1% |
| Zero shift | ≤±1%（F.S/Y） | Display | LCD screen |
| Operating language | English or Chinese | Gas unit | PPM, %VOL, %LEL |
| Temperature | -40～70℃ | Humidity | 0-95%RH |
| Explosion-Proof | ExiaⅡCT4 | Protection level | IP66 |
| Alarm mode | Sound, light and vibration | Operating time | 100hours（off pump） |
| Dimensions | 205*75*32mm | Weight | 300g |
Applications:
• Thermal power plant flue gas inspection
• Metallurgical & smelting workshop monitoring
• Coal mine, underground tunnel safety patrol
• Chemical plant gas leakage checking
• Confined space entry detection
• Waste incineration site monitoring
• Industrial boiler safety inspection
Remark: If you need gas or measuring range not listed on the above, pls send us your details requirments for further discussion.
