Product Description
OC-501 Automobile Exhaust Gas Analyzer adopts infrared absorption principle, equipped with microcomputer system to detect and measure 5 types of exhaust gas including HC, CO, CO2, O2 and NO. It supports full English menu operation, LCD screen display, data storage of up to 500 groups and built-in printer. The device realizes automatic zero adjustment and air-fuel ratio calculation, comes with RS232 serial communication interface for network connection. Optional functions include rotational speed and oil temperature measurement. Compatible with gasoline, LPG and CNG alternative fuel vehicles. Widely applied in vehicle inspection stations, environmental protection departments, university teaching laboratories, auto factories, repair plants and 4S shops for vehicle emission inspection.
Features:
- Used to measure the concentration of HC, CO, CO2, O2, NO in the Automobile Exhaust Gas;
- Full English Menu Operation;
- LCD (Liquid crystal) screen display;
- Can store and search 500 groups of data, built-in printer;
- Equipped with functions of plate number and time display;
- Two kinds of Test Function: General and Two-speed idle;
- Auto-zeroing, automatic calculation and show the air-fuel ratio;
- Equipped with RS232 digital serial communication interface to facilitate networking;
- Optional function: rotate speed and oil temperature Measurement;
- Measurable with Liquefied Petroleum Gas(LPG),Compressed Natural Gas(CNG),and gasoline and other alternative fuel vehicles;
- Can be equipped with the power inverter and inspect the gas with the car conveniently.
Technical Parameter:
| Working Environment | Temperature: -5~40℃;
humidity: ≤95%; Atmosphere pressure: 70.0~106kPa |
| Power supply | AC220V ±10%; 50Hz ±1Hz |
| Measurement range | HC: 0~10000 10-6 (ppm) vol
CO: 0~10.0 10-2 (%)vol CO2: 0~20.0 10-2(%)vol O2:0~25.0 10-2 (%) vol NO:0~5000 10-6(ppm)vol |
| Response Time | CO, HC, CO2≤10S ; NO, O2≤15S |
| Rotate speed(Optional) | 0~10000rpm |
| Oil temperature(Optional) | 0～120℃ |
| Indication Error | CO: ±5%
CO2: ±5% HC:±5% O2: ±5% NO: ±4% |
| Preheat time | 10 munites |
| Weight | 9.8KG |
| Packing Size | 420*320*250(mm) |
Application:
The Automobile Exhaust Gas Analyzer can be used in all levels of Traffic and public security inspection stations, Environment protection and exhaust treatment station, Teaching laboratory of University, Automotive and Motor manufacturer, Motorcycle factory, also the Automobile repair plants, 4S shop, Car repair and maintenance department, etc.
