Product Description
This portable PH3 (Phosphine) gas detector is developed for detecting highly toxic phosphine gas in industrial and storage scenarios. PH3 is widely used for grain fumigation and pest killing, improper operation will cause toxic gas leakage and threaten personnel safety.
Equipped with high‑performance electrochemical sensor, the unit achieves fast response and stable detection data. Real‑time LCD shows gas concentration; sound‑light‑vibration triple alarm will trigger once exceeding preset threshold. Built‑in large‑capacity storage supports 100,000 groups detection data recording for checking and exporting. Explosion‑proof compact handheld design makes it easy to carry for on‑site field work.
It provides reliable safety protection for fumigation operators, grain depot staff and chemical workers, effectively avoiding safety accidents caused by phosphine gas leakage.
Features
- Adopt high‑precision electrochemical PH3 sensor, rapid response
- Real‑time LCD screen display gas concentration value
- Sound, light and vibration triple alarm reminder
- Can record 100,000 groups of data for later review
- Explosion‑proof design, fit for harsh industrial working site
- Low battery reminder, lightweight handheld portable structure

Technical Parameter:
| Gas type | PH3 Phosphine |
| Working principle | Electrochemical sensor |
| Measuring range | 0-5ppm、20ppm、50ppm、100ppm、1000ppm. Support customized |
| Resolution | 0.01ppm 0.1ppm or customized |
| Concentration unit | %LEL, %Vol, ppb, ppm, mg/m3 |
| Precision | ±≤3%F.S |
| Repeatability | ≤±2% |
| Zero drift | ≤±1%(F.S/year) |
| Sampling mode | Pump-suction sampling (Flow rate of 300ml/minute) |
| Data storage | Can record 100000 group of measuring data |
| Response time | T90≤30s (different gas sensors have different response times) |
| Recovery time | ≤20s |
| Pre-heating time | ≤60s |
| Display | LCD dot matrix display of the Gas type, gas concentration unit, gas concentration data, time, battery status, data storage status; |
| Working temperature | -20℃~50℃(Special requirements need to be customized) |
| Working humidity | 10%-95%RH(non-condensing) |
| Working pressure | 86Kpa~106Kpa |
| Explosion-Proof grade | Ex ib IIC T4 Gb |
| Protection grade | IP54 |
| Alarm mode | Audible, visual. Two-color LED alarm light, sound≥75dB@25cm |
| Shell material | Aluminum alloy metal housing, ABS+PC |
| Power supply | 3.7VDC, 2600mAh,Rechargeable lithium battery
DC5V USB charger |
| Charge time | ≤6 hours |
| Working time | ≥12 hours (Normal temperature electrochemical sensor) |
| Power consumption | 0.5W |
| Dimensions | 200.5*64.8*35.5mm (L*W*H) |
| Weight | 0.46KG |
| Accessory | Box, instruction, USB charger , data line |
| Quality standard | GB15322.1-2003,GB3836.1-2010,GB3836.2-2010,GB3836.4-2010,GB12358-2006 |
Applications
- Grain depot, grain silo phosphine fumigation safety monitoring
- Grain and warehouse pest control fumigation site detection
- Chemical plant phosphine production workshop leakage inspection
- Pharmaceutical manufacturing production site gas monitoring
- Metallurgical processing workshop on‑site safety patrol
- Fumigation service company field operation detection
- Storage warehouse residual phosphine gas test
- Laboratory chemical reaction safety monitoring
