OC-9200 online dust monitor supports PM1, PM2.5, PM10, TSP particulate detection, as well as noise and full meteorological parameters including temperature, humidity, wind speed, wind direction, air pressure, rainfall and solar radiation. Adopts laser light scattering detection technology with automatic heating dehumidification compensation module to guarantee high-precision test data. Built-in 4G/GPRS wireless transmission, data real-time upload to cloud platform for remote viewing. IP55 outdoor waterproof dustproof, modular design with multiple installation ways, widely used for construction sites, urban road, mine dust pollution monitoring. We are professional Chinese manufacturer with factory direct supply, competitive wholesale price and customizable detection items.
Core Features
- Modular integrated design, convenient for large-scale grid layout of environmental monitoring stations
- One machine multi-index measurement, no need to replace sampling cutter, simultaneously monitor PM10, PM2.5, TSP (PM1 support customization)
- Industrial embedded processor, strong anti-interference ability, stable operation under harsh outdoor weather
- Unique automatic heating & dehumidification function, eliminate humidity interference to ensure accurate measurement data
- Long-life anti-jamming pump suction sampling structure, sampling period adjustable freely
- Stable industrial wireless transmission module, 4G/GPRS real-time cloud data upload
- Cloud platform remote data viewing function, no on-site operation required for data query
- Multiple installation solutions: pole mounting, tripod mounting, wall mounting
- Customizable detection items: meteorological parameters, particulate types can be adjusted as demand
- Dual power supply optional: AC220V mains power or solar panel off-grid power supply
Technical Parameter:
| Items | Description | Specification |
| Particle Modules | Monitor method | Continuously, automatically and real-time |
| Working principle | Light scattering technique | |
| Measurement data | PM2.5, PM10, TSP, customized | |
| Measuring range | 0~10mg/m3, customized | |
| Response time | ≤60s | |
| Resolution | 1ug/m3 | |
| Sampling flow | 1.3L/min, precision: ±3% | |
| Sampling time | Adjustable(Default is 5munites) | |
| Dehumidification | With the automatic dehumidification function module | |
| Fault alarm | Real-time display the fault alarm | |
| Noise monitor | Measuring range: 30~130dB (A) | |
| Sampling frequency: ＜1s | ||
| Dynamic analysis range: ≥100dB (A) | ||
| Frequency weighting: A, C,Z | ||
| Time weighting: F, S | ||
| Meteorological parameters | Temperature: Measuring range: -40℃~60℃, Precision: ±0.3℃ (20℃) | |
| Humidity: Measuring range: 0~100%RH, Precision:
±2%(5%RH~95%RH, 25℃) |
||
| Wind direction: Measuring range: 0~360°, Precision: ±5° | ||
| Wind speed: Measuring range: 0~30m/s, Precision: ±0.3m/s | ||
| Barometric pressure: Measuring range: 30~110Kpa, Precision: ±2.5pa | ||
System specification:
| Data efficient transmission rate | ≥95% |
| Remote control | Support for remote setting |
| Interface | RS485/RS232 port, Network port |
| Transmission network | Automatically and real-time upload data, optional 3G/4G/VPN/WIFI |
| Box material | Q235 spray, Stainless box optional |
| Scaffold material | Q235 |
| Scaffold height | Standard height is 4.5m, Flange connection(1m fixed underground, 2*1.5m+1*0.5m) |
| Lightning arrester | Length 1m, Q235 Galvanized material |
| Working environment | Temperature: -30~70℃
Humidity: 10%RH~90%RH Pressure: 65~108Kpa |
| Protection grade | IP55 |
| Power supply | AC220V/50Hz/Solar power (optional) |
Application Scenarios
- Construction site dust pollution real-time monitoring
- Urban road, municipal road traffic dust supervision
- Mining area, quarry, cement plant industrial particulate monitoring
- Park, residential area environmental air quality assessment
- Port, logistics yard, waste treatment plant dust emission supervision
- Urban environmental protection department grid air monitoring stations
