Description:
The OC-850 portable multi gas detector is a customizable air quality monitoring device specially configured for CH2O(Formaldehyde), TVOC, O3(Ozone) detection.
It supports dual sampling modes including diffusion sampling and optional 1L/min pump suction sampling. Fitted with imported high-precision electrochemical & PID industrial sensors, the detector features fast response and stable measuring data.
With Ex ib IIB T3 explosion-proof certification and IP65 dust & water resistance, the device adopts LCD real-time display plus sound-light-vibration triple alarm, together with local data storage and long battery life. Widely applied in indoor renovation acceptance, factory workshop, laboratory, sewage plant, disinfection room and environmental law enforcement air inspection work.
Features:
- Real-time simultaneous measurement of CH2O formaldehyde, TVOC and ozone O3; flexible customization for 1~5 gas types
- Dual sampling design: free selection between diffusion sampling and 1L/min pump suction sampling
- Original imported industrial high-precision sensors, response time controlled within 10 seconds
- Sound, light and vibration triple alarm reminder, effective alarm reminder even in noisy working space
- Intuitive LCD screen displays gas concentration, gas name and current alarm working status synchronously
- Built-in data storage module, can save up to 9999 groups of alarm records for later data review and traceability
- Ex ib IIB T3 explosion-proof structure + IP65 waterproof and dustproof casing, adapt to complicated working conditions
- Super long battery life: 100 hours continuous working time under pump closed status
- Switchable Chinese & English system menu; support multiple units: PPM, %VOL, %LEL, mg/m³
- Wide operating temperature range of -40℃ ~70℃, stable detection performance in high and low temperature environments
- Internal stainless steel filter screen protects sensors, keeps smooth air intake and ensures long-term test accuracy
Technical Specification:
| Gas Detected | CH2O, Formaldehyde, TVOC, Ozone O3 | ||
| Detection principle | Electrochemical sensor(CH2O,O3), PID sensor(TVOC) | ||
| Sampling Method | Diffusion type or Pump suction(1L/min) | ||
| Measure Range | CH2O: 0~10ppm, TVOC: 0~10ppm, O3: 0~1ppm; Support customized | ||
| Resolution | CH2O: 0.01 ppm, TVOC: 0.01 ppm, O3: 0.01 ppm | ||
| Precision | ≤± 3% F.S. | ||
| Data store | 9999 groups alarm information | ||
| Response Time | ≤10S | Recovery Time | ≤10S |
| Repeatability | ≤±1% | Linearity error | ≤±1% |
| Zero shift | ≤±1%（F.S/Y） | Display | LCD screen |
| Operating language | English or Chinese | Gas unit | PPM, %VOL, %LEL |
| Temperature | -40～70℃ | Humidity | 0-95%RH |
| Explosion-Proof | ExiaⅡCT4 | Protection level | IP66 |
| Alarm mode | Sound, light and vibration | Operating time | 100hours（off pump） |
| Dimensions | 205*75*32mm | Weight | 300g |
Applications:
- Indoor decoration & new house formaldehyde acceptance testing
- Office, shopping mall, classroom public space air quality monitoring
- Ozone disinfection workshop, water treatment disinfection area safety detection
- Factory workshop VOCs waste gas monitoring and environmental governance inspection
- Laboratory, clean room air hazard monitoring
- Environmental protection law enforcement portable air sampling inspection
- Hotel, real estate indoor air safety testing
Remark: If you need gas or measuring range not listed on the above, pls send us your details requirments for further discussion.
