Description:
Features:
- Simultaneous real-time detection of CO2 carbon dioxide and SF6 sulfur hexafluoride; support flexible customization of 1~5 kinds of gas detection schemes according to customer requirements
- Two sampling modes are optional: natural diffusion sampling and 1L/min constant flow pump suction sampling, convenient for internal gas extraction of closed electrical equipment
- CO2 equipped with anti-interference NDIR infrared sensor, SF6 adopts high-sensitivity dedicated infrared leakage sensor, overall response time ≤10 seconds
- Sound, light and vibration triple early warning system, even in noisy power workshop environment, it can remind staff to deal with gas abnormality in time
- Clear LCD display screen synchronously displays gas concentration value, gas name and real-time alarm status, with clear reading and simple observation
- Built-in data storage chip, can record and store up to 9999 groups of alarm data for later inspection records sorting and data traceability management
- Ex ib IIB T3 explosion-proof structure matched with IP65 dustproof and waterproof shell, adapt to complex indoor power room and outdoor temporary inspection environment
- Strong lasting power supply performance: the device can work continuously for 100 hours when the built-in air pump is closed
- The system supports one-click switching between Chinese and English interfaces, compatible with PPM, %VOL, %LEL, mg/m³ and other mainstream gas measurement units
- Wide working temperature range of -40℃ ~70℃, keeping stable detection accuracy in high temperature power room and low temperature outdoor inspection environment
- The built-in stainless steel filter screen filters dust and water mist, protects the internal infrared sensor components and ensures stable and smooth gas intake
Technical Specification:
| Gas Detected | CO2 carbon dioxide and SF6 sulfur hexafluoride | ||
| Detection principle | NDIR infrared sensor(CO2), Infrared sensor(SF6) | ||
| Sampling Method | Diffusion type or Pump suction(1L/min) | ||
| Measure Range | CO2: 0~10000ppm, SF6: 0~1000ppm, Support customized | ||
| Resolution | CO2:1 ppm, SF6: 0.1 ppm | ||
| Precision | ≤± 3% F.S. | ||
| Data store | 9999 groups alarm information | ||
| Response Time | ≤10S | Recovery Time | ≤10S |
| Repeatability | ≤±1% | Linearity error | ≤±1% |
| Zero shift | ≤±1%（F.S/Y） | Display | LCD screen |
| Operating language | English or Chinese | Gas unit | PPM, %VOL, %LEL |
| Temperature | -40～70℃ | Humidity | 0-95%RH |
| Explosion-Proof | ExiaⅡCT4 | Protection level | IP66 |
| Alarm mode | Sound, light and vibration | Operating time | 100hours（off pump） |
| Dimensions | 205*75*32mm | Weight | 300g |
Applications:
- Substation, high voltage switch room SF6 gas leakage daily inspection
- Power cabinet, ring main unit, GIS equipment SF6 sealing performance testing
- Indoor office, computer room, data center CO2 concentration real-time monitoring
- Electric power maintenance personnel safety protection detection during equipment overhaul
- Underground power pipe gallery air quality and gas hidden danger inspection
- Factory closed workshop, laboratory CO2 ventilation monitoring
- New energy power station electrical room routine safety testing
Remark: If you need gas or measuring range not listed on the above, pls send us your details requirments for further discussion.
