Product Overview
It synchronously measures particulate concentration, harmful gas concentration, temperature, humidity, air pressure, wind speed & wind direction, and is equipped with pollutant over-standard early warning function, bringing higher precision and easier operation for ambient air quality supervision.
- Custom pump-suction sampling for pollutant gas is available according to customer actual demands
- Terminal data is uploaded to cloud platform in real time via wireless network, facilitating source pollution monitoring and management
- Adopts dynamic heating (DHS) humidity compensation function plus cross-interference compensation algorithm for gaseous pollutants to guarantee high data accuracy
- Built-in breakpoint resume transmission function, the effective data transmission rate can reach more than 99%
- Equipped with 4G full-network wireless communication, supporting synchronous data upload on multiple platforms
- Realizes linkage control function with peripheral pollution abatement equipment
- External devices such as outdoor LED display screens and alarm lamps can be additionally configured
Detailed Technical Parameters
| Category | Item | Detection Method | Measuring Range | Resolution | Accuracy / Indication Error | Lower Detection Limit |
|---|---|---|---|---|---|---|
| Gaseous Pollutants | SO₂ Sulfur Dioxide | Electrochemistry | 0 ~ 500 ppb | 0.1 ppb | ±10% FS | 5 ppb |
| NO₂ Nitrogen Dioxide | Electrochemistry | 0 ~ 500 ppb | 0.1 ppb | ±10% FS | 5 ppb | |
| O₃ Ozone | Electrochemistry | 0 ~ 500 ppb | 0.1 ppb | ±10% FS | 5 ppb | |
| CO Carbon Monoxide | Electrochemistry | 0 ~ 20 ppm | 0.1 ppm | ±10% FS | 0.2 ppm | |
| TVOC Total Volatile Organic Compounds | PID Photoionization Detection PID | 0 ~ 10 ppm | 0.1 ppm | ±5% FS | 1 ppm | |
| Particulate Matter | PM2.5 | Laser Scattering | 0~1000 / 0~10000 / 0~30000 μg/m³ | 0.1 μg/m³ | ±10% | 2 μg/m³ |
| PM10 | Laser Scattering | 0~1000 / 0~10000 / 0~30000 μg/m³ | 0.1 μg/m³ | ±10% | 2 μg/m³ | |
| TSP Total Suspended Particulates | Laser Scattering | 0~1000 / 0~10000 / 0~30000 μg/m³ | 0.1 μg/m³ | ±10% | 2 μg/m³ | |
| Meteorological Parameters | Temperature | / | -40 ~ 123.8 ℃ | 0.01 ℃ | ±0.4 ℃ | / |
| Humidity | / | 0 ~ 100 %RH | 0.01 %RH | ±3 %RH | / | |
| Atmospheric Pressure | / | 70 ~ 120 kPa | 1 Pa | ±250 Pa | / | |
| Wind Speed | / | 0 ~ 60 m/s | 0.1 m/s | ±1 m/s | / | |
| Wind Direction | / | 0 ~ 359 ° | 1 ° | ±1 ° | / |
Working Principle & Transmission Mode
- Gas components: Electrochemical sensor + PID photoionization detection
- Dust concentration: Laser light scattering method
- Humidity correction: Dynamic heating dehumidification module + anti-interference algorithm
- Data transmission: 4G full network transmission, cloud platform storage & viewing, breakpoint resume uploading
Application Scenarios
- Urban grid ambient air quality automatic monitoring
- Industrial park, chemical plant, waste incineration plant pollution source monitoring
- Road, tunnel, port atmospheric environmental monitoring
- Residential area, school, hospital, park ecological air monitoring
- Environmental impact assessment, factory unorganized exhaust emission monitoring
- Municipal environmental law enforcement, regional air pollution tracing
Company Profile
Henan Oceanus Company, located in Henan, a land with a long history and profound cultural heritage, has been dedicated to the research, development, production, and sales of Safety and Environmental products since its establishment. With exquisite technology and outstanding quality, we have won widespread recognition in the global marketing.
01. Business areas
As a leader in the field of gas detectors and dust monitor system, Henan OCEANUS Import and Export Co., Ltd. continues to expand its business scope and provide customers around the world with customizable gas detectors and AQMS of various types and specifications.
02. Values and ideas
Our company upholds the core values of integrity and quality service, focusing more on friendship with our customers. We always adhere to integrity management, customer-centered, and provide a full range of pre-sales, sales, and after-sales services to ensure that customers can be worry-free when using our products.
03. Global Service Network
We have a comprehensive global service network, offering timely, professional pre-sales consultation, after-sales service, and technical support for overseas users. Regardless of where users are located, they can enjoy our attentive and thoughtful service.
04. Customer Service
With excellent products and services, Henan OCEANUS Import and Export Co., Ltd.’s gas detectors and environment monitoring devices have been exported to more than 100 countries around the world and have won widespread praise.
